THE BUKH BETA LIFEBOAT DIESEL ENGINES SET NEW STANDARDS FOR LOW EXHAUST EMISSIONS AND CONTRIBUTE TO THE REDUCTION OF MARINE ENVIRONMENTAL POLLUTION
They comply with the Tier standards which have been made technically possible through the incorporation of pre-combustions chamber injection instead of common rail / unit injection. This eliminates the need for
vulnerable electronic devices for control of fuel volumes and improves the operational reliability. This design allowed the engines to pass and obtain the US Coast Guard approval for use as lifeboat engines.
Further to these features, the BUKH BETA series demonstrates outstanding qualities when it comes to the relationship between weight and power.
SPECIFICATIONS
| Engine rotation (looking forward) | Anti-clockwise |
| Propeller rotation (looking forward) | Clockwise |
| Number of cylinders | 4 |
| Bore and stroke | 78.0 x 78.4 mm (3.07 x 3.09 in) |
| Swept volume | 1498 cm3 (91.41 cu in) |
| Cycle | 4-stroke |
| Cooling system (standard) | Keel-cooling |
| Inclination, max, fore and aft | 15° |
| Heel, max, continuous | 25 |
| Fuel consumption, cruising | 6.5 l/h (1.44 galls/h) |
| Air consumption | 1956 l/min |
| Exhaust temperature | 500C |
| Electric starter motor | 12V (1.2 kW) |
| Charging alternator | 175 kg (386 lbs) |
| Engine crankcase vent syst | Closed |
| Electronic engine diagnostic | NO |
| Max continuous rating (ISO3046) at | 36 HP (26.5 kW) |
| at RPM | 3000 |
| Reverse-reduction gear ratio (standard) | 3:1 |
| Installation drawing No. | 009M8301 |
